Snom HD30L
Lobby telephone
Key features
- Antibacterial housing
- Hospitality features
- Customisable faceplate
- Power over Ethernet (only)
Elegant, corded SIP lobby phone
The Snom HD30L is a modern hotel lobby phone with a clear and slim design. It has no keypad and starts automatic dialling to a specified destination when the handset is lifted. This means that dialling is impossible.
With the Snom lobby phone, you can ensure a smooth, intuitive user experience in any hotel lobby, waiting area or corridor. The antibacterial housing protects against germs and is easy to clean. Thanks to the inlay on the receiver shell, the H30L is easy to customise. Table or wall mounting possible. Three additional programmable buttons provide additional functions if required.
DSGVO conform by Design: The Snom HD30L also sets standards in terms of data protection and security. It was developed in accordance with GDPR requirements and does not store any personal data such as dialled phone numbers. Remote setup and maintenance are carried out exclusively via servers in Germany, ensuring the highest security standards.
*Faceplates not included
Antibacterial housing
The housing coating offers effective protection against bacteria
GDPR by design
No data storage of guest data!
Customisation
As with almost all appliances in the Hospitality series, you can order customised inserts for the lower shell.
Technical data
Basics and equipment
Product information
- Lobby phone HD30L + corded handset
- Colour: gunmetal black
- PN 00007019
Equipment
- Anti-bacterial housing
- Sturdy, solid construction
- Fully customisable faceplate for hotel branding and dialing instructions
Placement
- Indoor
- Desktop
- Nightstand
- Wall mounting
Dimensions and weight
Dimensions (H × W × D, approx.)
- Corded handset on the base cradle, desk mounted: 182 mm × 53 mm × 146 mm
- Corded handset on the base cradle, wall mounted: 216 mm × 53 mm × 56 mm
Weight (approx.)
- Corded handset on the base cradle: 400 g
Indicators and keys
LED indicators
- Corded handset: 2 LED indicators
- Mute status indication: 1 red LED
- Speakerphone mode: 1 red LED
Dedicated audio keys
- Mute (with red LED)
- Speakerphone mode (with red LED)
- VOL+ → Volume +
- VOL- → Volume -
Number of dedicated audio keys
- 4 dedicated audio keys
Audio devices and features
Audio devices
- Corded handset
- Microphone
- Handset earpiece
- External speaker
Audio features
- Hearing aid compatible (HAC)
- Built-in assignable ringtones
Interfaces and connections
Power options
- Power over Ethernet (PoE)
- IEEE 802.3af
- PoE Class 2
Wired interfaces
- Telephone base
- Network connectivity: RJ45-8P8C socket
- Gigabit Ethernet (GbE)
- Handset cord: custom socket
- Corded handset: custom socket
Administration interfaces and setup
Configuration and setup
- Configuration and setup via voice menu
- Configuration and setup via menu-driven web user interface (WUI)
Management
- Advanced SIP configuration tool for easy mass deployment and phone monitoring
- Secure Redirection And Provisioning Service (SRAPS) support
Networking technologies and protocols
Network protocols
- SIP (RFC 3261)
Network features
- VLAN support
- Gigabit Ethernet (GbE)
Call features
SIP
- 1 SIP identity / account
Calling features
- Automatic dialling when the handset is lifted
- Dialling is disabled
- Speed dialling via function keys
- Mute microphone via dedicated function key
- Multicast paging
Environmental conditions
Operating ambient temperature
- 5 °C - +45 °C
Humidity
- 5 % - 95 %
- Non-condensing
Package contents
Hardware
- Telephone base
- Handset
- Handset cord: 330 mm
- Footstand
- Wall mount kit
Ethernet cables
- 2 Ethernet cables
- Cable length: approximately 125 mm and 2 m
Documentation
- Quick Installation Guide
Snom accessories and compatible devices
PoE injector
- A5
- PN 00004065
- Available separately
Power
- Power over Ethernet (PoE)
- IEEE 802.3af, Class 2
